ExtractionTek Solutions MEP™

Contact for Pricing

The Modular Extraction Platform (MEP™) from ExtractionTek Solutions is a closed-loop extraction solution, capable of handling 10-30 liters of material.
With a patented cascading design, the MEP™ provides operators the capability to process more material in a shorter time frame.

SKU: 4201822 Category:

Description

Capacity: 5-30L (or up to 15lbs of material per hour) – depending on model selected
Unit size: 15 Square feet (5′ x 3′)
Sub-Cool injection technology allows operators the option to inject and recover solvent without heating and cooling the operating tank.
Accepts propane, butane, and blended solvents
Peer reviewed by third party engineers and certified for operation in CO, CA, NV, OR, WA, PA, and MD
Certified for ASME SECTION VIII, IFC, NFPA 58, 3-A Sanitary Standard, C1D1, and UL21
Modular Platform – Stainless steel frame with locking casters
Rapid Recovery collection vessel with viewports
Sub-Cool injection coil system

Includes an MTA TAEevo 220 Volt, 5000-watt recirculating chiller

Includes an MTA TAEevo 220 Volt, 5000-watt recirculating chiller
Dual ETS expansion filter
Dual Julabo Corio CD-BC4 hot water recirculating system
Built-in Haskel 83354 two-stage modified recovery pump
Air tool port accessory kit
Innovative air-driven Piab (C1D1 vacuum pump)
50 lbs. steel D.O.T. operating tank
Includes an MTA TAEevo 220 Volt, 5000-watt recirculating chiller
