Description
Electrical requirements
208-240V, single phase, 50/60 Hz
Tube material
High purity quartz
Min. working temperature
Ambient
Max. working temperature
Zone1/Zone2: 1200°C
Max. constant working temperature
Zone1/Zone2: 1100°C
Constant working temperature under vacuum
1000°C
Rated vacuum pressure
0.001 Pa / 0.0075 millitorr / 0.00001 mbar
Rated positive pressure
0.02 MPa / 150 torr / 3 psi
Refractory lining
Mitsubishi (Japan) high quality 1500 grade fiber alumina
Heating element type
Zone1/Zone2: Kanthal (Sweden) A1 2.0 coil wire
Thermocouple type
Zone1/Zone2: K
Temperature controller
Shimaden fp93 (Japan) with 4 patterns and 40 segments (i.e. 4 x 10 segments or 2 x 20 segments)
Max/recommended heating rate
20°C/min 10°C/min
Heating zone length
Zone1: 8 inches Zone2: 8 inches
Constant temp zone length
Zone1: 4 inches Zone2: 4 inches
Temperature controller precision
/- 1°C
Vacuum level (cold)
0.1 Pa
Vacuum sealing flange kit
Stainless steel vacuum sealing flanges with one vacuum gauge, two valves and four thermal ceramic blocks.
Compliant
ETL tested to UL and CSA standards (optional), CE
