250C UL Certified 7.5 CF Vacuum Oven w/ 5 Shelves & SST Tubing

8,550.00$

SST (stainless steel) tubing refers to internal tubing and compression. external tubing not included.

SKU: 4200644 Category: Tag:

Description

 Electric
 110V /-10% 60Hz 1-PH 13.6A, 1,500 watts  or 220V /-10% 50/60Hz 1-PH 6.8A, 1,500 watts

 Heater
 300 watts x 5, built into 5 aluminum shelves, for the fastest, most energy efficient and uniform heating

 Chamber
 Size: 22 x 23.5 x 25″ Material: Stainless steel Capacity: 7.5 cubic feet

 Temperature control
 Controller: low proportional gain, microcomputer PID controlled with LCD display Range: ambient to 250°C (or 480°F) Display units: Fahrenheit or Celsius Uniformity: /- 5% of setpoint Dwelling timer range: 1 to 9999 minutes Warm-up time to 100°F: 45 minutes Warm-up time to 480°F: 2 hours 15 minutes

 Vacuum
 Ultimate vacuum level: better than 500 microns/millitorrs (may vary based on your altitude, click here to learn more) Mechanical gauge range: 0 to 30 inch mercury Vacuum port: KF25 flange x 1 Vent port: KF25 flange x 1 Vacuum pump: Sold separately

 Weight
 Unit: 410 Lbs, shipping: 630 Lbs

 Dimensions (WxDxH)
 Unit: 34.5 x 33 x 35.5″ Shipping: 40 x 39 x 43″

 Shelves
 Heated shelves: 5 non-removable aluminum shelves, 22 x 23.25″ (WxD) each Optional stackable aluminum shelves: 22 x 23.25 x 2.25″ (WxDxH) Total area without stackable shelves: 512 x 5 = 18 sq ft or 2560 sq inch Total area with 5 stackable shelves: 512 x 10 = 36 sq ft or 5120 sq inch Distance between shelves (without stackable shelves): 4.5 inches Distance between shelves (with 5 stackable shelves): 2.25 inches Max. load capacity per shelf: 20 Lbs

 Door gasket material
 Silicone or Viton

 Observation window
 1/2″ tempered safety glass

 Safety
 Built-in circuit breaker Overheat shutoff protection Secondary over-temp protection dial

 In-door lights
 White LED

 Warranty
 2 years

 Compliance
 UL (E482564), CE

 Download
 Product brochure
