6.6KW Hi-Frequency Compact Induction Heater 100-500KHz

5,790.00$

Note: This model only available in 220 volt single phase.

SKU: 4200481 Category: Tag:

Description

 Max. input current
 30 A (45A single-phase circuit breaker required)

 Power
 208-240V, 50/60Hz, single-phase

 Power distribution cord
 8-gauge 3-conductor Max 40A (8/3 SOOW)

 Output frequency
 100-500 KHz

 Max. oscillating power
 6.6 KW

 Duty cycle

 80%

 Heating timer
 0.1-99.9 seconds

 Dwelling timer
 0.1-99.9 seconds

 Air cooling
 Rear fan

 Water pressure
 ≥ 40 PSI (you may use tap water)

 Water flow
 > 0.8 gallon (3 liters) per minute

 Induction coil
 0.75″x1.25″x2″x9″ IDxODxHxL (5mm diameter copper tubing) Custom made coils available at extra cost.

 Weight
 Unit: 45 Lb, shipping: 66 Lb

 Size
 Unit: 23x11x20″, shipping: 28x15x25″

 Remote foot switch
 7 feet
