Description
Max. input current
30 A (45A single-phase circuit breaker required)
Power
208-240V, 50/60Hz, single-phase
Power distribution cord
8-gauge 3-conductor Max 40A (8/3 SOOW)
Output frequency
600-1100 KHz
Max. oscillating power
6.6 KW
Duty cycle
80%
Heating timer
0.1-99.9 seconds
Dwelling timer
0.1-99.9 seconds
Air cooling
Rear fan
Water pressure
≥ 40 PSI (you may use tap water)
Water flow
> 0.8 gallon (3 liters) per minute
Unit weight
Power supply: 35 Lb, handheld coil station: 3 Lb
Shipping weight
50 Lb
Unit dimensions
Power supply: 21x10x18″, handheld coil station: 4x6x4″
Shipping dimensions
27x15x28″
Connection cables
6 feet
Remote foot switch
7 feet
