Description
Model
D16
Electrical requirements
110V (±10%) 60Hz 1-Phase 8.89A
Performance
Temperature range: -20°C to -40°C
Compressor
Number of compressors: two Cooling method: direct cooling Defrost mode: manual Style: parallel Refrigerant: R290
Chamber
Dimensions: 25.5 x 22.5 x 24.5″ (WxDxH) Number of chambers: two Material: stainless steel Volume: 15.9 Cu Ft
Shelf
Quantity: two in each chamber, four in total Style: fixed Material: stainless steel
Door
2
Working environment
– Temperature: 16°C to 32°C – Humidity: <80% Rh - Altitude: < 2000 m / 6561 Ft - Stable, well-ventilated platform with no excessive dust - Keep freezer at least 12 inches from any walls or ceiling - Use dedicated power, do not share outlet - Extension power cable should be less than 10 feet is required - Freezer and power outlet should be grounded properly - Avoid direct sunlight, water spill and do NOT use freezer outdoor - Clean condenser fins and remove frost inside chamber at least once a month - Important! Do not plug in your unit. Leave your Ai refrigerator or freezer for 24 hours before turning the unit on for the first time.
Access port
Two
Communication
Remote alarm 4-20mA transmitter, USB, RS-485
Built-in swivel casters
Four, two with brakes
Noise level
52 dBA
Unit/shipping weight & dimensions
320 Lbs / 345 Lbs 30.5 x 26.5 x 73" / 37.5 x 34.5 x 80" (WxDxH)
Safety
Compressor over-temp protection Compressor power surge delay protection Power failure protection Low battery, door open, filter clogging, system failure, sensor error, condenser overheat alarms External door with lock
Warranty
One year
