Description
Power
110V, 1ph, 14 FLA, also available in 220V
Chamber size
5 cubic foot
Chamber material
Stainless Steel
Chamber dimensions
18.25” W x 24” D x 18.25” H
Port
Rear KF-25 port 1″ diameter
Vacuum
3/8″ barb
Vent
1/4″ barb
Certified
NRTL
Shelves
5 Included in 1″,2″ and 3″ height
Agilent IDP7, 5.4CFM dry scroll pump
Included
MAX EVAP vacuum oven to pump connection kit
Included
KF-25 Hardware
Included
Filter Required
No
Ultimate Vacuum
2 x 10^-2 Torr
Controller
PID controller /Analog knobs
Display
° F
Stability
/-4 °F at 105 °F
Max temperature
240 °F
Unit weight
249 lbs
Shipping weight
449 lbs
Unit dimension
18.75″ W x 26.5″ D x 24.5″ H
Shipping dimensions
30 x 30 x 45″
Made in the USA
Perfect for removing water or residual solvents
PID controller included
Multiple sizes and types available
