Description
Voltage:
230V/60Hz
Working Temperature Range:
20° to 300°C
Temperature Stability:
/- 0.01°C
Heating Capacity:
3 kW
Pump Capacity Flow Rate:
22 to 26 l/min
Pump Capacity Flow Pressure:
5.8 to 10.2 psi
Usable Bath Opening (W x L / D):
8.7 x 5.9 / 7.9 in.
Filling Volume:
3.2 gal
Dimensions (W x L x H):
11.8 x 16.9 x 18.5 in.
RS232/RS485 interface – for online communication
VFD Comfort Display
Integrated programmer – for 10 progam steps
Keypad for set points, warning/safety value and menu functions
ICC (Intelligent Cascade Control), self-optimizing temperature control
TCF Temperature Control features – to optimize control behavior
ATC3 3-Point-Calibration
Pt100 external sensor connection – for measurement and control
Smart pump, electronically adjustable pump stages
Connections for solenoid valve and HSP booster pump
Voltage:
230V/60Hz
Working Temperature Range:
20° to 300°C
Temperature Stability:
/- 0.01°C
Heating Capacity:
3 kW
Pump Capacity Flow Rate:
22 to 26 l/min
Pump Capacity Flow Pressure:
5.8 to 10.2 psi
Usable Bath Opening (W x L / D):
8.7 x 5.9 / 7.9 in.
Filling Volume:
3.2 gal
Dimensions (W x L x H):
11.8 x 16.9 x 18.5 in.
