Description
Temperature range
-90 to 100°C
Ambient temperature
5 to 40 °C
Temperature Stability
±0.02
Resolution
.01°C
Temperature Display
VFD/LCD
Heating capacity
1.3 kW
Cooling capacity at 20 °C
1 kW
Flow rate
22-26 L/Min
Flow pressure
5.8 – 10.2 (psi)
Flow suction
2.9 – 5.8 (psi)
Connections
M16x1
Cooling of compressor
Air
Barbed fittings diameter/ (inner diameter)
8/(12) mm
Included fittings
2 each barbed fittings for tubing 8 and 12 mm inner dia. (pump connections M16x1 female).
Volume
8 Liters
Size (W x L / D)
5.1 x 5.9 / 6.3 (W x L / D) inches
Refrigerant for unit
R404A
Filling volume for refrigerant 1 (g)
500
Refrigerant stage 2 (g)
R508B
Filling volume for refrigerant 2 (g)
270
Power requirement V / Hz / A
230/60/16
Classification according to DIN12876-1
Classification III (FL)
Weight
297 LBS
Size (W x L x H)
21.7 x 23.6 x 36.2 inches
Active Cooling Control
Improved insulation – to prevent ice build up
Liquid level display
VFD comfort display
Keypad for setpoints and alarms
Backlit LCD display
Self-optimizing temperature control
Electronically adjustable pump stages
RS485/RS232 data connections
Integrated programs steps – 6 x 60 program steps
Connections for HSP booster pump and solenoid valve
For flammable bath fluids Classification III (FL) according to DIN 12876-1
Data subject to change without notice.
