Description
Model
CORIO
Type
Refrigerated/Heating Circulator
Temperature control
PID controlled
Temperature stability
±.03
Working temp. range
-20 to 150°C
Display
LED
Display resolution
.01 to .1°C
Heating capacity
2 kW
Cooling capacity
at 20°C/ .22 kW
Flow rate l/min
15
Flow pressure
.35 bar
Pump connection
M16x1
Bath size
13 x 15 / 15 (W x L / D cm)
Barbed fitting
8/12 (inner diameter / mm)
Bath volume
3 to 4 liters
Refrigerant
R134a
Working ambient temp.
5 to 40 °C
Weight
26 kg
Bath tank and cover
Stainless steel/ intergrated
Cooling for compressor
Air
Included
2 each barbed fitting for tubing 8 and 12 mm inner dia. (pump connections M16x1 male)
Bright display – for easy reading
Insulated parts – for user protection against temperatures
Ready for operation in just a few steps
Integrated timer
Larger bath size
Easily change between external and internal circulation with the flip of a switch
Front-located controls
Easily moved with handles front and rear
Special drain tap – makes emptying the reservoir a cinch
Temperature control of samples in a circulator bath
Temperature control of an external application
Measuring cells, refractometers, polarimeters, photometers, viscometers, fermenters, electrophoresis chambers, chromatography columns, rotary evaporators, rheometers, and more.
