Description
Electrical requirements
208-240VAC, 50/60 Hz, single phase
Tube material
Quartz
Min. working temperature
Ambient
Max. working temperature
Zone1/Zone2/Zone3: 1200°C
Max. constant working temperature
Zone1/Zone2/Zone3: 1100°C
Constant working temperature under vacuum
Zone1/Zone2/Zone3: 1000°C
Rated vacuum pressure
0.001 Pa / 0.0075 millitorr / 0.00001 mbar
Rated positive pressure
0.02 MPa / 150 torr / 3 psi
Refractory lining
Mitsubishi (Japan) high quality 1600 grade fiber alumina
Heating element type
Zone1/Zone2/Zone3: Kanthal (Sweden) A1 2.0 resistance coil wire
Thermocouple type
Zone1/Zone2/Zone3: K
Temperature controller
Shimaden fp93 (Japan) with 4 patterns and 40 segments (i.e. 4 x 10 segments or 2 x 20 segments)
Max heating rate
20°C/min
Recommended heating rate
10°C/min
Heating zone length
Zone1: 8 inches Zone2: 8 inches Zone3: 8 inches
Constant temperature zone length
Zone1: 4 inches Zone2: 4 inches Zone3: 4 inches
Temperature controller precision
/- 1°C
Vacuum sealing flange kit
Stainless steel vacuum sealing flanges with one vacuum gauge, two valves and four thermal ceramic blocks.
Compliance
ETL tested to UL and CSA standards (optional), CE
