Description
Electrical requirements
208-240VAC, 50/60 Hz, single phase
Tube material
High purity (99%) alumina ceramic
Min. working temperature
300°C
Max. working temperature
1700°C
Max. constant working temperature
1600°C
Rated vacuum pressure
0.001 Pa / 0.0075 millitorr / 0.00001 mbar
Rated positive pressure
0.02 MPa / 150 torr / 3 psi
Refractory lining
Mitsubishi (Japan) high quality 1800 grade fiber alumina
Heating element type
MoSi2
Thermocouple type
B
Temperature controller
Shimaden fp93 (Japan) with 4 patterns and 40 segments (i.e. 4 x 10 segments or 2 x 20 segments) Or Yudian (China)
Max heating rate
10°C/min
Recommended heating rate
5°C/min
Heating zone length
Zone1: 8 inches Zone2: 8 inches Zone3: 8 inches
Constant temp zone length
Zone1: 6.5 inches Zone2: 6.5 inches Zone3: 6.5 inches
Temperature controller precision
/- 1°C
Vacuum sealing flange kit
Stainless steel vacuum sealing flanges with one vacuum gauge, two valves and four thermal ceramic blocks.
Compliance
ETL tested to UL and CSA standards (optional), CE
