Description
Model
R100
Electrical requirements
110V 60Hz or 220V 50/60Hz, 1-Phase, 250W
Reaction glass vessel capacity
26 gallons (100L)
Cooling/heating jacket capacity
8 gallons (30L)
Glass material
High borosilicate glass 3.3
Rotation controller
Digital controller with variable frequency drive Rotation speed: 50 to 500 rpm
Maximum jacket pressure
4.4 psi or 0.03 MPa
Drain valve
Flush seal design with large opening and flat flange clamp
Agitator
Style: impeller Material: 304 stainless steel with PTFE liner
Funnel
Pressure equalizing
Vacuum gauge
Mechanical
Swivel caster
Four
Glass vessel temperature range
-110°F to 400°F
Vacuum level
< 700 torrs
Vacuum sealing
Glass or PTFE
Drain port ground clearance
13.5 inches
Unit dimesions (WxDxH)
28 x 42 x 95"
Shipping dimensions
26 x 88 x 45"
Shipping weight
460 Lbs
Download
Product brochure
Compliance
ETL tested to UL and CSA standards
