Description
Model
R20ex
Electrical requirements
220V 50/60Hz single phase
Explosion-proof parts (Made in USA)
* Explosion-proof motor: 1/3 HP, 250 watts * Explosion-proof controller and enclosure * Explosion-proof power connection and cable management PSI peer reviewed, for use with Ethanol, Pentane, Hexane, Heptane, Isopropyl Alcohol/Acetone, and Methanol.
Volume
Main vessel: 20 liters (5.3 gallons) Fluid jacket: 6 liters (1.6 gallons)
Material
Vessel, condenser, feeding funnel and receiving flask: borosilicate glass 3.3 Agitator: 304 stainless steel with PTFE coating Sealing gaskets: PTFE
Glass vessel temperature range
-80°C to 200°C (-112°F to 400°F)
Vacuum & pressure
Ultimate vacuum: < 700 Torrs Display: mechanical vacuum gauge Maximum fluid jacket pressure: 4.4 psi or 0.03 MPa
Weight and dimensions
Unit: 20 x 27 x 80" (WxDxH fully setup) Drain port ground clearance: 13" Shipping: 24 x 75 x 31" (WxDxH), 280 lbs
Warranty
One year
