Description
Model
R10
R20
R50
R100
Electrical requirements
110V 60Hz or 220V 50/60Hz, 1-Phase
Power
90W
140W
250W
Reaction glass vessel capacity
2.6 gallons (10L)
5.3 gallons (20L)
13 gallons (50L)
26 gallons (100L)
Glass material
High borosilicate glass 3.3
Rotation controller
Digital controller with variable frequency driveRotation speed: 50 to 500 rpm
Maximum jacket pressure
4.4 psi or 0.03 MPa
Drain valve
Flush seal design with large opening and flat flange clamp
Agitator
Style: impeller Material: 304 stainless steel with PTFE liner
Vacuum gauge
Mechanical
Glass vessel temperature range
-110°F to 400°F
Vacuum level
< 700 torrs
Vacuum sealing
Glass and PTFE
Drain port ground clearance
15 inches
13 inches
12.5 inches
13.5 inches
Unit dimension (WxDxH)
18 x 26 x 78″
20 x 27 x 80″
26 x 33 x 85″
28 x 42 x 95″
Shipping dimensions
24 x 67 x 26″
24 x 75 x 31″
27 x 80 x 32″
26 x 88 x 45″
Shipping weight
240 Lbs
262 Lbs
330 Lbs
390 Lbs
Download
Product brochure
Compliance
ETL tested to UL and CSA standards, CE (optional)
