Description
Model
R20
Electrical requirements
110V 60Hz or 220V 50/60Hz, 1-PH, 90W
Reaction glass vessel capacity
5.3 gallons (20L)
Cooling/heating jacket capacity
1.6 gallons (6L)
Glass material
High borosilicate glass 3.3
Rotation controller
Digital controller with variable frequency drive
Maximum jacket pressure
4.4 psi or 0.03 MPa
Drain valve
Flush seal design with large opening and flat flange clamp
Agitator
Style: impeller Material: 304 stainless steel with PTFE liner
Condenser
Dual-cooling coil design
Funnel
Pressure equalizing
Vacuum gauge
Mechanical
Swivel caster
Four
Glass vessel temperature range
-110°F to 400°F
Vacuum level
< 700 torrs
Vacuum sealing
Glass or PTFE
Drain port ground clearance
13 inches
Reactor dimensions (WxDxH)
20 x 27 x 80"
Shipping dimensions
24 x 75 x 31"
Shipping weight
265 Lbs
