Description
Maximum Batch Capacity:
10 Gallons / 38 Liters
Footprint (L x W x H ft.):
2’ x 2’ x 5’
Warranty:
1 Year
Chiller Electrical:
230V/1~/12A
Chiller Dimensions (L x W x H in.):
26” x 19” x 34”
Chiller Weight:
220lbs
Vacuum Pump Electrical:
115V/1~/4A
Vacuum Pump Dimensions (L x W x H in.):
12” x 9” x 9”
Vacuum Pump Weight:
30 lbs
Oil Heater Electrical:
230V/3~/33.7A or 460V/3~/18A
Oil Heater Dimensions (L x W x H in.):
37”x 18” x 54”
Oil Heater Weight:
600 lbs
Variable Frequency Drive Mixer Electrical:
208 – 240V/1~ or 3~ input, 3~ output/1A
Total Amps 240V:
52
Total Amps 480V:
26
