250C UL 14 Shelf Max 5 Cu Ft 5 Sided Heating Vacuum Oven

6,590.00$

SST (stainless steel) tubing refers to internal tubing and compression. external tubing not included. Oven comes standard with 7 shelves.

SKU: 4200642 Category: Tag:

Description

 Electric
 110V or 220V /-10% 50/60Hz 1-PH, 3,000 watts

 Chamber
 Size: 19.75 x 21.5 x 19.75″ Material: Stainless steel Capacity: 5.0 cubic feet

 Heater
 5-sided heating (left 600W, right 600W, top 600W, bottom 600W, back 200W x 3)

 Temperature control
 Controller: low proportional gain, microcomputer PID controlled with LCD display Range: ambient to 250° (or 480°F) Display units: Fahrenheit or Celsius Uniformity: /- 7% of setpoint Dwelling timer range: 1 to 9999 minutes Warm-up time to 100°F: 45 minutes Warm-up time to 480°F: 2 hours 15 minutes

 Vacuum
 Ultimate vacuum level: better than 500 microns/millitorrs (may vary based on your altitude, click here to learn more) Mechanical gauge range: 0 to 30 inch mercury Vacuum port: KF25 flange Vent port: KF25 flange Vacuum pump: Sold separately

 Weight
 Unit: 410 Lbs, shipping: 630 Lbs

 Dimensions (WxDxH)
 Unit: 32.25 x 28 x 30″ Shipping: 38 x 37 x 38″

 Shelves
 Shelf size: 19.25 x 21 x 0.5″ (WxDxH) Material: aluminum Style: pan-shape Capacity: 14 shelves max. Comes standard with oven purchase: 7 shelves Total area with 14 shelves: 39.3 sq ft or 5660 sq inch Distance between the most adjacent shelves: 1.25″

 Door gasket material
 Silicone or Viton

 Observation window
 1/2″ tempered safety glass

 Safety
 Built-in circuit breaker Overheat shutoff protection Secondary over-temp protection dial

 In-door lights
 White LED (pre-installed)

 Compliance
 ETL certified to UL and CSA standards

 Warranty
 2 years
