HUBER Unistat T305 300°C with Pilot ONE – 208V


The new Huber multi-touch controller Pilot ONE offers a brilliant 5.7″ touchscreen with graphic functions and a comfortable navigation menu. All important operating parameters and temperature values are neatly displayed on the touchscreen. Thanks to the new favourites menu, the one-click operation and the integrated technical glossary the operation is very easy, just like on a smartphone. Integrated USB and Ethernet ports allows connection to a PC or network, e.g. for remote control or data transmission.

SKU: 4200899 Category: Tag:


General information & temperature controller

Temperature range
65…300 °C

Temperature stability
±0.02 °C

Temperature control
TAC, self-optimizing (True Adaptive Control)

Display resolution
0.01 °C

Alarm message
optical, acoustical

Pilot ONE  (E-grade “Professional”)

Safety class
III / FL

Protection class

Dimensions (W x D x H)
425 x 250 x 631 mm  |  16.73 x 9.84 x 24.84 inches

39 kg  |  86 pounds

Heating / cooling capacity

Heating capacity
4,8 kW

Circulation pump

Pressure pump max.
45  lpm ; 0.9  bar  |  11.89 gpm ; 13.05 psi

Pump connection
M24x1,5 AG male

Permissible viscosity
50 mm²/s


Pt100 connection

Analogue input
via optional Com.G@te

Analogue output
via optional Com.G@te

Digital interface
RS232, Ethernet, USB Device, USB Host

Operating data

Permissible ambient temp.
5…40 °C

Filling volume min.
1.45 Liters  |  0.38 gal

Volume of expansion
2.8 Liters  |  0.74 gal

Power supply
208V 3~ 60Hz
