Description
Electrical requirements
110 or 220 Volts 60Hz single phase, 0.2 HP, 150 Watts
Application
Rotary Evaporation/Distillation (medium volatility solvents <110C B.P., volume ~ 1 liter), Vacuum ovens - small, pumping harsh vapors & gases
Pumping rate
0.9 cfm
Ult. vacuum pressure
9 torr
Maximum vacuum
29.6 in. Hg
Vacuum connection
3/8" hose barb
Adjustable vac./gas ballast
Yes
Pump dimensions (LxWxH)
13.8 x 6.8 x 8.8"
Shipping dimensions (LxWxH)
21 x 14 x 15"
Pump weight
21.25 Lb
Shipping weight
25 Lb
Certification
UL, CSA
Warranty
One year
Downloads
User's manual, product brochure
