Ai 20L Non-Jacketed Glass Reactor with 200°C Heating Jacket


Ai R-series glass reactors are designed for synthetic reaction of different types of materials in a controlled temperature and vacuum environment. Each reactor features adjustable stirring speeds and a constant pressure feeding funnel that allows you to add material to the vessel at a uniform and controlled speed. The built-in condenser makes it possible to recover some materials, also at a controlled rate of speed.

SKU: 4200841 Category: Tag:



 Electrical requirements
 110V or 220V, 50/60Hz 1-PH, 90W

 Reaction glass vessel capacity
 5.3 gallons (20L)

 Glass material
 High borosilicate glass 3.3

 Rotation controller
 Digital controller with variable frequency drive Rotation speed: 50 to 500 rpm

 Drain valve
 Flush seal design with large opening and flat flange clamp

 Style: impeller Material: 304 stainless steel with PTFE liner

 Pressure equalizing

 Vacuum gauge

 Glass vessel temperature range
 -110°F to 400°F

 Vacuum level
 < 700 torrs  Vacuum sealing  Glass and PTFE  Drain port ground clearance  13 inches  Unit dimensions (WxDxH)  20 x 27 x 80"  Shipping dimensions  24 x 75 x 31"  Shipping weight  262 Lbs  Download  Product brochure  Compliance  ETL tested to UL and CSA standards (optional)  Warranty  One year
